The emerging spectrum of COVID-19 neurology: clinical, radiological and laboratory findings
Ross W. Paterson,1,2,3,4,* Rachel L. Brown,1,5,* Laura Benjamin,6,7 Ross Nortley,1,8 Sarah Wiethoff,1 Tehmina Bharucha,9 Dipa L. Jayaseelan,1,10 Guru Kumar,2 Rhian E. Raftopoulos,11 Laura Zambreanu,1,10 Vinojini Vivekanandam,9 Anthony Khoo,9 Ruth Geraldes,8 Krishna Chinthapalli,8 Elena Boyd,8 Hatice Tuzlali,8 Gary Price,9 Gerry Christofi,9 Jasper Morrow,1 Patricia McNamara,9 Benjamin McLoughlin,9 Soon Tjin Lim,9 Puja R. Mehta,9 Viva Levee,9 Stephen Keddie,1 Wisdom Yong,12 S. Anand Trip,1,12 Alexander J.M. Foulkes,1,10 Gary Hotton,9 Thomas D. Miller,13 Alex D. Everitt,14 Christopher Carswell,14 Nicholas W.S. Davies,14 Michael Yoong,15 David Attwell,16 Jemeen Sreedharan,11 Eli Silber,11 Jonathan M. Schott,1 Arvind Chandratheva,6 Richard J. Perry,6 Robert Simister,6 Anna Checkley,9 Nicky Longley,9 Simon F. Farmer,9 Francesco Carletti,9 Catherine Houlihan,9 Maria Thom,1 Michael P. Lunn,1 Jennifer Spillane,9,17 Robin Howard,9,17 Angela Vincent,1,18 David J. Werring,6 Chandrashekar Hoskote,9 Hans Rolf Jäger,1 Hadi Manji1,9,* and Michael S. Zandi1,9,* for the UCL Queen Square National Hospital for Neurology and Neurosurgery COVID-19 Study Group
*These authors contributed equally to this work.
VC The Author(s) (2020). Published by Oxford University Press on behalf of the Guarantors of Brain.
This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted reuse,
distribution, and reproduction in any medium, provided the original work is properly cited.
1
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 3 of 63
Brain
Abstract
Preliminary clinical data indicate that severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) infection is associated with neurological and neuropsychiatric illness. Responding to this, a weekly virtual coronavirus disease 19 (COVID-19) neurology multi- disciplinary meeting was established at the National Hospital, Queen Square, in early March 2020 in order to discuss and begin to understand neurological presentations in patients with suspected COVID-19-related neurological disorders. Detailed clinical and paraclinical data were collected from cases where the diagnosis of COVID-19 was confirmed through RNA PCR, or where the diagnosis was probable/possible according to World Health Organization criteria. Of 43 patients, 29 were SARS-CoV-2 PCR positive and definite, eight probable and six possible. Five major categories emerged: (i) encephalopathies (n = 10) with delirium/psychosis and no distinct MRI or CSF abnormalities, and with 9/10 making a full or partial recovery with supportive care only; (ii) inflammatory CNS syndromes (n = 12) including encephalitis (n = 2, para- or post-infectious), acute disseminated encephalomyelitis (n = 9), with haemorrhage in five, necrosis in one, and myelitis in two, and isolated myelitis (n = 1). Of these, 10 were treated with corticosteroids, and three of these patients also received intravenous immunoglobulin; one made a full recovery, 10 of 12 made a partial recovery, and one patient died; (iii) ischaemic strokes (n = 8) associated with a pro- thrombotic state (four with pulmonary thromboembolism), one of whom died; (iv) peripheral neurological disorders (n = 8), seven with Guillain-Barré syndrome, one with brachial plexopathy, six of eight making a partial and ongoing recovery; and (v) five patients with miscellaneous central disorders who did not fit these categories. SARS-CoV-2 infection is associated with a wide spectrum of neurological syndromes affecting the whole neuraxis, including the cerebral vasculature and, in some cases, responding to immunotherapies. The high incidence of acute disseminated encephalomyelitis, particularly with haemorrhagic change, is striking. This complication was not related to the severity of the respiratory COVID-19 disease. Early recognition, investigation and management of COVID-19-related neurological disease is challenging. Further clinical, neuroradiological, biomarker and neuropathological studies are essential to determine the underlying pathobiological mechanisms, which will guide treatment. Longitudinal follow-up studies will be necessary to ascertain the long-term neurological and neuropsychological consequences of this pandemic.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
2
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 4 of 63
Author affiliations:
1 University College London, Queen Square Institute of Neurology, London, UK
2 Darent Valley Hospital, Dartford, Kent, UK
3 UK Dementia Research Institute, London, UK
4 UK Dementia Research Institute
5 UCL Institute of Immunity and Transplantation, London, UK
6 UCL Institute of Neurology, Stroke Research Centre, Russell Square House, London, UK
7 University of Liverpool, Brain Infections Group, Liverpool, Merseyside, UK
8 Wexham Park Hospital, Berkshire, UK
9 National Hospital for Neurology and Neurosurgery, University College London Hospitals NHS Foundation Trust, Queen Square, London, UK
10 Watford General Hospital, Watford, Hertfordshire, UK
11 King’s College Hospital, Denmark Hill, London, UK
12 Northwick Park Hospital, Harrow, London, UK
13 Lister Hospital, Stevenage, Hertfordshire, UK
14 Imperial College London, London, UK
15 Barts and The London NHS Trust, London, UK
16 UCL, Department of Physiology, London, UK
17 Guy’s and Saint Thomas' Hospitals NHS Trust, London, UK
18 University of Oxford, Nuffield Department of Clinical Neurosciences, John Radcliffe Hospital, Oxford, UK
Correspondence to: Dr Michael S. Zandi PhD FRCP
University College London Queen Square Institute of Neurology
London WC1N 3BG
UK
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
3
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 5 of 63
Brain
E-mail: m.zandi@ucl.ac.uk
Running title: The emerging spectrum of COVID-19 neurology
Keywords: COVID-19; SARS-CoV-2; encephalitis; ADEM
Abbreviations: ADEM = acute demyelinating encephalomyelitis; COVID-19 = coronavirus disease 19; GBS = Guillain-Barré syndrome; IVIG = intravenous immunoglobulin; SARS- CoV-2 = severe acute respiratory syndrome coronavirus 2
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
4
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 6 of 63
Introduction
Since December 2019, almost 10 million cases and 500 000 deaths due to the novel coronavirus, severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2), have been reported worldwide (WHO situation report). Although the respiratory system complications of coronavirus disease 19 (COVID-19) have been the most frequent and life threatening, there are increasing reports of central and peripheral nervous system (PNS) involvement. These neurological complications have included encephalopathy (Helms et al., 2020), meningo-encephalitis (Moriguchi et al., 2020), ischaemic stroke (Beyrouti et al., 2020), acute necrotizing encephalopathy (Poyiadji et al., 2020), and Guillain-Barré Syndrome (GBS) (Toscano et al., 2020). Radiological series have shown infarcts, microhaemorrhages, features of posterior reversible encephalopathy syndrome, or nerve root enhancement (Franceschi et al., 2020; Mahammedi et al., 2020). Zanin and colleagues (2020) have described a case of CNS demyelination post-COVID-19. Detailed neurological assessment and investigation is challenging in those who are critically ill, limiting the opportunity to delineate the underlying pathophysiology and hence, treatment options. The postulated mechanisms of the various neurological syndromes include, either individually or in combination, direct viral neuronal injury (Zubair et al., 2020), a secondary hyperinflammation syndrome (Mehta et al., 2020), para- and post-infectious inflammatory or immune-mediated disorders, or the effects of a severe systemic disorder with the neurological consequences of sepsis, hyperpyrexia, hypoxia, hypercoagulability and critical illness.
Here we describe the detailed emerging spectrum of neurological disorders encountered in 43 COVID-19 patients referred to the National Hospital, Queen Square COVID-19 multidisciplinary team meeting (COVID-MDT), run in partnership with infectious disease and virology colleagues at University College London Hospital (UCLH).
Materials and methods
We reviewed retrospectively the clinical, radiological, laboratory and neuropathological findings from patients referred to the COVID-MDT neurology/encephalitis and neurovascular multi-disciplinary team meetings. The cases summarized were discussed between 9 April and 15 May 2020. Neurological syndromes developing after definite,
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
5
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 7 of 63
Brain
probable or possible COVID-19, which were likely to be associated with COVID-19 on clinical grounds, were included. Cases for which a more likely alternative pathology was found were excluded.
The probability of COVID-19-related neurological disease was determined using WHO criteria [‘Global surveillance for human infection with coronavirus disease (COVID-19)’]: (i) definite (SARS-CoV-2 RNA PCR positive from nasopharyngeal swab, CSF or pathological specimen); (ii) probable (clinical and laboratory features highly suggestive of COVID-19— lymphopenia, raised D-dimer, suggestive chest radiology in the absence of PCR evidence) (Guan et al., 2020); and (iii) possible, in whom temporal or laboratory features indicate an association but another cause was also found (Ellul et al., 2020). Where possible, laboratory results shown are those nearest to onset of neurological symptoms.
The classification of the severity of COVID-19 infection was adapted from Wu and McGoogan (2020). Mild disease included patients with non-pneumonia or mild pneumonia, severe disease included patients with dyspnoea and hypoxia requiring supplementary oxygen, and critical disease included patients with respiratory failure requiring assisted ventilation, septic shock, and/or multi-organ dysfunction. Where possible, laboratory results shown are those nearest to onset of neurological symptoms. Consensus clinical criteria were used to classify individuals with specific neurological syndromes including encephalitis (Solomon et al., 2012; Graus et al., 2016), acute demyelinating encephalomyelitis (ADEM) (Pohl et al., 2016), and GBS (Willison et al., 2016). We obtained assent and/or written consent from patients or from their relatives. This study is approved and registered as a service evaluation of our MDT (ref 06-202021-SE) at University College London Hospitals NHS Trust.
Some patient details have been submitted for publication as case reports by their treating physicians: Patients 7 and 11 (Khoo et al., in press), Patient 12 (Zambreanu et al., in press), Patient 15 (Dixon et al., 2020), and Patients 36, 37, 39, 41 and 42 (Beyrouti et al., 2020).
Data availability
The data that support the findings of this study are available from the corresponding author, upon reasonable request. The data are not publicly available due to ethical restrictions e.g. their containing information that could compromise the privacy of the patients reported.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
6
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 8 of 63
Results
The patients included 24 males and 19 females with ages ranging from 16–85 years. Twenty- three of our patients (53%) were non-white. On the basis of a positive nasal-pharyngeal throat SARS-CoV-2 PCR test, 29 were defined as definite COVID-19, eight were probable and six were possible for this association. The severity of the COVID-19 symptoms varied from mild to critical. The patients presented with a wide range of CNS and PNS features including neuroinflammatory diseases and stroke from 6 days before and up to 27 days following the onset of the COVID-19 symptoms. The patients are divided into five categories based on the clinical, neuroradiological, neurophysiological and laboratory features, as summarized in Table 1. We provide a brief summary of the neurological phenotypes in Tables 2–4. Full details of the clinical, viral, immunological, radiological and neurophysiological investigations, management and treatment responses are detailed in the Supplementary material.
CNS syndromes
Encephalopathies
The 10 patients described (Patients 1–10, six female, four male; four White, five Black and one Asian) had a parainfectious or septic encephalopathy with delirium. These patients (e.g. Vignette A) were mostly >50 years old and presented with confusion and disorientation, with psychosis in one, and seizures in another. Neuroimaging was within normal limits, and CSF studies were normal when performed. Treatments were largely supportive with 7 of 10 making a complete recovery, and 2 of 10, a partial recovery at the time of discharge (Table 2 and Supplementary material).
Vignette A: acute parainfectious encephalopathy with psychosis
A 55-year-old female (Patient 7), with no previous psychiatric history, was admitted with a 14-day history of fever, cough, muscle aches, breathlessness, as well as anosmia and hypogeusia. She required minimal oxygen treatment (oxygen saturation 94% on room air) and was well on discharge 3 days later. The following day, her husband reported that she was confused and behaving oddly. She was disorientated and displayed ritualistic behaviour such
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
7
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 9 of 63
Brain
as putting her coat on and off repeatedly. She reported visual hallucinations, seeing lions and monkeys in her house. She developed ongoing auditory hallucinations, persecutory delusions, a Capgras delusion and complex systematized delusional misperceptions. She displayed intermittently aggressive behaviour with hospital staff and her family. Her psychotic symptoms persisted after disorientation improved. Brain MRI, EEG and lumbar puncture were normal. Her clinical course fluctuated over 3 weeks with a trend towards improvement, albeit after the introduction of haloperidol, followed by risperidone.
Neuroinflammatory syndromes
Twelve patients (Patients 11–22, 27–66 years old; eight female, four male; four White, three Black, three Asian; two other/mixed) presented with inflammatory CNS syndromes. Two had an encephalitis; one (Patient 11, Vignette B) had features of an autoimmune encephalitis with opsoclonus, stimulus sensitive myoclonus and convergence spasm. Although brain imaging, EEG and CSF were normal, the clinical picture was highly suggestive of an autoimmune brainstem encephalitis. The second encephalitis patient (Patient 12) presented with confusion and a single seizure, with MRI abnormalities suggestive of autoimmune or ‘limbic’ encephalitis in the thalami, medial temporal regions and pons (Fig. 1A–D, Table 2 and Supplementary material).
Nine patients were categorized within the spectrum of ADEM (e.g. Vignette C). Four patients had haemorrhagic change on imaging, including microbleeds; and one had necrosis. Two patients had myelitis in addition to brain imaging changes, and one further had myelitis with normal brain imaging. Patient 17 (Vignette D) with acute haemorrhagic leucoencephalitis (based on clinical and imaging features) failed to respond to corticosteroids and required decompressive craniectomy for incipient brain herniation; a brain biopsy at the time of surgery showed evidence of perivenular inflammation supporting aggressive hyper-acute ADEM. She made significant recovery after the decompression followed by intravenous immunoglobulin (IVIG), but requires ongoing rehabilitation. Patient 15 developed a severe necrotizing encephalitis that resulted in death. Patient 16 was unusual in presenting with a GBS and subsequently developed an ADEM-like illness (Fig. 2H–O, Vignette E).
Despite the striking imaging findings of these patients (Figs 1, 2 and 4), the CSF parameters were abnormal in only half. In none of the cases tested were specific antibodies (e.g. to
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
8
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 10 of 63
NMDAR, MOG, AQP4, LGI1 or GAD) identified in the serum or CSF. Treatments were with corticosteroids in nine, and IVIG in three. A full clinical response was seen in 1 of 12, partial recovery at the time of writing in 10 of 12, and one patient died.
Vignette B: post-infectious probable brainstem and cortical autoimmune encephalitis
A 65-year-old female (Patient 11), with a 2-year history of cognitive decline and presumed sporadic early onset Alzheimer’s disease, presented with right hand and then widespread involuntary movements, 6 days after fever, cough and myalgia. She had difficulty speaking and became disorientated and confused, complaining of well-formed visual hallucinations of people inside her house and objects flying around the room. She complained of deteriorating vision, with difficulty reading, and intermittent double vision. On admission she had widespread stimulus sensitive myoclonus involving the tongue and all four limbs with marked hyperekplexia. There was episodic opsoclonus and prominent convergence spasm on visual fixation. She had a non-fluent aphasia with oral apraxia, difficulty repeating sentences and was only able to follow single stage commands. MRI brain, EEG and CSF examination were normal. SARS-CoV-2 PCR was positive on nasopharyngeal swab. Levetiracetam and clonazepam were used to treat her myoclonus, and 2 weeks after onset of neurological symptoms, she received a course of steroids for a clinical diagnosis of presumed post- infectious autoimmune encephalitis affecting cortex and brainstem. Cognition and visual symptoms improved although there were on-going symptoms at the time of writing.
Vignette C: ADEM with haemorrhage in a critically ill patient
A 52-year-old male (Patient 13) presented with a 10-day history of cough, fever, dyspnoea and myalgia. On admission he was hypoxic and non-invasive ventilation was commenced. He had bilateral chest X-ray changes consistent with COVID-19 and SARS-CoV-2 RNA PCR was positive. Oxygen requirements increased and mechanical intubation was required. On Day 17 of intensive care admission he was slow to wean from sedation. His conscious level was impaired (responding to pain only) despite a prolonged withdrawal from sedation. He was hyper-reflexic with lower limb clonus. Brain MRI showed bilateral white matter changes
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
9
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 11 of 63
Brain
with haemorrhage (Fig. 1E–H). There was slow and still on-going neurological improvement over 4 weeks with supportive treatment alone, which continues at the time of writing.
Vignette D: acute haemorrhagic leukoencephalopathy form of ADEM requiring decompressive craniectomy
A 47-year-old female (Patient 17), previously well and who worked in a high-risk occupation for COVID-19, presented with right-sided headache and left hand numbness. This was preceded by 7 days of cough, fever and shortness of breath. On the day of presentation, she had persistent severe headache and progressive onset of left-sided numbness followed by left- sided weakness including the face. A few hours later, she was drowsy, with severe left upper limb weakness, mild left leg weakness and hemisensory loss. CT head imaging demonstrated marked right hemisphere vasogenic oedema with midline shift. She required 4 l of oxygen and had lower zone chest X-ray and CT chest changes compatible with probable COVID-19 as well as lymphopenia, and elevated D-dimer. Head MRI demonstrated severe right hemispheric vasogenic oedema with a leading edge on contrast imaging, and smaller areas of T2 hyperintense changes in the left hemisphere, in keeping with a diagnosis of an acute haemorrhagic leukoencephalopathy form of ADEM. She was treated with high dose intravenous methylprednisolone (1 g daily for 5 days). After 48 h of treatment her conscious level fell, she developed a fixed dilated right pupil and underwent emergency right hemi- craniectomy. She subsequently received oral prednisolone 60 mg daily and 5 days of IVIG. She was extubated 4 days postoperatively and continues to improve clinically, and is able to weight bear with support. Pathological findings from brain biopsy taken at surgery supported a diagnosis of hyperacute ADEM (Fig. 2E–G). The brain tissue was negative in PCR for SARS-CoV-2.
Vignette E: sequential para-infectious involvement of central and peripheral nervous system
A 52-year-old male (Patient 16) presented with a 3-day history of headache, back pain, vomiting and progressive limb weakness. There was bilateral facial and neck weakness, symmetrical upper and lower limb flaccid (proximal > distal) weakness, generalized areflexia, extensor plantar responses and preserved sensation. MRI of the neuroaxis was normal except for gadolinium enhancement of the cervical and lumbar roots (Fig. 2H and L).
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
10
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 12 of 63
CSF was acellular, with a raised protein. Nerve conduction studies supported a diagnosis of GBS and he was treated with IVIG. On Day 3 of admission, he deteriorated with increasing weakness, dysphagia, ophthalmoplegia, and lymphopenia. Due to type-2 respiratory failure, he required ventilation. The patient became febrile (38.9°C), with increasing oxygen requirements, and antibiotics were commenced. Chest CT showed bilateral pulmonary infiltrates. SARS-CoV-2 RNA PCR was positive on throat swab, but negative in CSF. On Day 5, he became unresponsive and a repeat brain MRI showed a pattern of T2 symmetrical widespread white matter hyperintensities, which progressed further on Day 12 (Fig. 2I–K and M–O). Intravenous methylprednisolone (IVMP, 1 g/day) was given for 5 days, with neurological improvement following treatment on Day 3: eyes opened spontaneously, he could obey commands, mouth words, and move both hands. Two weeks after completion of IVMP the patient was alert, breathing without assistance, talking and able to flex both arms.
Stroke
Eight patients (Patients 23–30; aged 27–64, six male, two female, five White, two Asian, one Black) had ischaemic stroke in the context of hypercoagulability and a significantly raised D- dimer (>7000 mg/l) in each of the six cases measured. Thrombus was observed in large intra- and extra-cranial vessels in four patients. Four patients had pulmonary thromboembolism (e.g. Patient 27, Vignette F) (Table 4).
Vignette F: ischaemic stroke with concurrent pulmonary embolism
A 58-year-old male (Patient 27), previously independent in a high-risk occupation for developing COVID-19, presented with acute onset aphasia and dense right-sided weakness. This was preceded by a 2-day history of lethargy and cough. He was found to be drowsy and unresponsive. Brian CT confirmed a proximal middle cerebral artery thrombus and territorial infarct (Fig. 3A–D) with local mass effect. He was transferred to a specialist hospital due to risk of vasogenic oedema leading to malignant middle cerebral artery syndrome. Due to the degree of established infarction neither intravenous thrombolysis nor mechanical thrombectomy were appropriate. CT angiogram also showed a saddle pulmonary embolism, which was managed conservatively with split dose low molecular weight heparin. His condition was critical in the hyperacute period with fluctuating level of consciousness and
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
11
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 13 of 63
Brain
tachycardia, but stabilized. His D-dimer was in excess of 80 000 μg/l on admission but reduced to 2800 μg/l after 7 days of anticoagulation. Lupus anticoagulant was positive. The patient was discharged to a rehabilitation unit on Day 8.
Peripheral nervous system
Seven patients (Patients 31–38) with GBS were seen (aged 20–63, all male, five White, one Black, one other), with onset of neurological symptoms from 1 day before to 21 days after typical COVID-19 symptoms. One patient developed a brachial plexopathy onset 2 weeks after COVID-19 symptoms. Of this group, half had definite COVID-19, three requiring intensive care. All GBS patients were treated with IVIG; the patient with brachial plexopathy received corticosteroids. All but two of this group have started to make partial recovery at the time of writing.
Miscellaneous
The remaining five patients (Patients 39–43) were difficult to categorize. They comprised myelopathy with normal imaging; one patient with bilateral abducens nerve palsy due to intracranial hypertension (pseudo-tumour cerebri) who presented with abdominal pain, diarrhoea and rash and had possible cardiac involvement with COVID-19; a complex paediatric case with a congenital developmental disorder and stable epilepsy who developed non-convulsive status epilepticus; and a patient with a bacterial brain abscess with Streptococcus intermedius. One patient, a 27-year-old male with acute myeloid leukaemia, COVID-19 lung disease and seizures with some encephalopathy, demonstrated a significant burden of microhaemorrhages (Patient 41; Fig. 3E–H). He had been treated with Gilteritinib as part of his acute myeloid leukaemia therapy.
Summary of key features
Despite the wide range of initial presentations, with a better appreciation of the five main categories outlined above, the key clinical features and investigations could be proposed as summarized in Table 1. None of the eight patients tested for SARS-CoV-2 PCR in CSF were
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
12
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 14 of 63
positive, and none of the autoantibodies seen in autoimmune forms of encephalitis (NMDAR, LGI1) or encephalomyelitis (AQP4, MOG) were detected in serum or CSF samples. Raised D-dimers were, predictably, highly raised in those patients with stroke but were also above normal levels, and occasionally markedly elevated in each of the other groups. Those with encephalopathies improved without specific treatments. The patients with inflammatory CNS diseases were treated with corticosteroids (n =10) and corticosteroids in combination with IVIG (n = 3) and have had variable outcomes to date, but the follow-up period is still short. One patient with ADEM made some improvement spontaneously without specific treatment. Six of seven patients with GBS had partial response to treatment at the time of writing.
Discussion
The widespread effects of COVID-19 include neurological disorders but there have been, to date, no detailed clinical reports of their nature (Guan et al., 2020; Helms et al., 2020; Mao et al., 2020; Varatharaj et al., 2020). Our London and regional cohort describes a range of neurological syndromes including encephalopathies, para- and post-infectious CNS syndromes including encephalitis, ADEM with haemorrhage and necrotic change, transverse myelitis, ischaemic stroke and GBS.
The neurological complications of SARS-CoV2 have similarities to those described in the other coronavirus epidemics, specifically severe acute respiratory syndrome (SARS) in 2003, and Middle East acute respiratory syndrome (MERS) in 2012. The cases described in those reports included encephalopathy, encephalitis and both ischaemic and haemorrhagic stroke attributed to hypercoagulability, sepsis and vasculitis, and GBS (Umapathi et al., 2004; Tsai et al., 2005; Kim et al., 2017). However, overall numbers of infected individuals were much smaller, 8000 with SARS and 2500 with MERS, and neurological presentations were few in comparison with those being recognized in the current pandemic.
In a series from Wuhan, 78 of 214 COVID-19 patients, recruited over 4 weeks, developed neurological manifestations. These patients tended to be more severely affected, older and with more comorbidities and, for some, the neurological symptom was the first presentation of COVID-19 (Mao et al., 2020). However, apart from stroke in six patients (2.8%), the neurological features could be due to viral infection (loss of smell and taste) or to the consequences of severe systemic illness in an intensive care setting, such as sepsis and
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
13
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 15 of 63
Brain
hypoxia. More specific details came from 64 consecutive patients reported by the Strasbourg group (Helms et al., 2020) with agitation in 40/58 (69%), confusion in 26/40 (65%) and corticospinal tract signs in 39/59 (67%). MRI abnormalities were seen in 22 patients with meningeal enhancement, ischaemic stroke and perfusion changes. CSF examination was negative for SARS-CoV-2 in all seven cases tested. There are isolated case reports in the literature of myoclonus (Rábano-Suárez et al., 2020) and demyelination (Varatharaj et al., 2020; Zanin et al., 2020).
Ten of our patients had transient encephalopathies with features of delirium, and psychosis in one. Delirium with agitation is described in case reports and in the larger studies mentioned above, and cognitive dysexecutive syndromes have been reported at discharge (Rogers et al., 2020). While our patients had transient syndromes, detailed neuropsychological testing and follow-up is required to determine the extent of cognitive dysfunction in recovery, and to examine psychiatric and psychological factors (Brown et al., 2020). The underlying mechanisms for the encephalopathy may be multifactorial resulting from the combined or independent effects of sepsis, hypoxia and immune hyperstimultion (‘cytokine storm’) (Mehta et al., 2020).
Two of our cases had a probable autoimmune encephalitis, one with typical clinical features of opsoclonus and myoclonus, and another with typical radiological images as seen in ‘limbic’ encephalitis (Graus et al., 2016). These patients did not have NMDAR, LGI1 or related autoantibodies (Supplementary Table 1). The issue of whether SARS-CoV-2 will trigger a significant number of cases of autoimmune encephalitis, with probable antibody- mediated mechanisms, will become clear in time.
The cluster of cases with an ADEM-like illness warrants close surveillance. ADEM, an immune-mediated demyelinating disorder, is a disease mainly of children (Pohl et al., 2016), with an adult incidence in the UK of 0.23/100 000 (Granerod et al., 2010; Absoud et al., 2015). The nine cases described were accrued over a 5-week period. In Greater London (population 8.9 million, Office of National Statistics 2018), we would expect to see this incidence of cases in 5 months, which indicates that COVID-19 is associated with an increased incidence of ADEM. SARS-CoV-2 was not detected in CSF in any of the eight patients tested and the single neuropathological sample obtained did not confirm the presence of SARS-CoV-2 in brain tissue, and was supportive of the diagnosis of ADEM. While we cannot exclude the possibility of direct CNS infection in some cases, without further
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
14
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 16 of 63
neuropathological studies or development of accurate CSF viral markers and serological testing, the imaging and clinical features are most supportive of a para- or post-infectious disease mechanism. Long-term follow-up is now required to establish the natural history of the cases that we have identified.
The GBS cases were not unexpected. The temporal relationship between the COVID 19 respiratory illness and the onset of symptoms would be consistent with a post-infectious immune-mediated mechanism. Up to two-thirds of patients with GBS describe an antecedent respiratory or gastroenterological illness. The most common pathogens include Campylobacter jejuni, cytomegalovirus, Mycoplasma pneumonia, HIV and more recently the Zika virus. The first report of GBS and SARS-CoV-2 from Italy describes five cases of GBS out of a total of 1200 admissions (Toscano et al., 2020). The expected incidence of GBS is 0.6–2.7/100 000/year (Willison et al., 2016) and further epidemiological and mechanistic study is required to determine if there is a true increase in incidence of GBS in COVID-19 patients. Our GBS cases appeared to be similar to conventional GBS patients with respect to clinical presentation, neurophysiology showing demyelinating changes in the majority of patients, CSF parameters and the response to treatment with IVIG.
Stroke associated with a generalized thrombotic predisposition in COVID-19 is of particular interest. Four out of the eight patients had cardiovascular risk factors for stroke including atrial fibrillation. Four also had pulmonary emboli. COVID-19 is associated with a pro- thrombotic state and highly elevated D-dimer levels, and abnormal coagulation parameters have been shown to be associated with poor outcome (Tang et al., 2020). The frequent occurrence of cerebral microbleeds seen in some of the patients, however, was unexpected (Fig. 3). Cerebral microbleeds are usually due to extravasation of red blood cells, and in the context of COVID-19 could be due to endothelial dysfunction related to viral binding to the ACE-2 receptors expressed on endothelial cells. Indeed, a recent report described direct viral infection of the endothelial cell and diffuse endothelial inflammation in multiple organ systems (Varga et al., 2020). The strokes we have encountered with COVID-19 have been severe, and further epidemiological study is required to determine the association between COVID-19 and stroke; randomized trials to determine the optimal use of antiplatelet drugs, low molecular weight heparin and other stroke therapies are required.
Muscle pain and elevated creatinine kinase have been reported as relatively common manifestations of SARS-CoV-2 infection (Chen et al., 2020; Guan et al., 2020; Huang et al.,
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
15
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 17 of 63
Brain
2020) and there are case reports of rhabdomyolysis (Rivas-Garcia et al., 2020). Like other large neurological case series (Varatharaj et al., 2020), we did not observe such cases, but this could reflect referral bias to our MDT, which was set up to discuss the most challenging and severe cases.
Within our cohort of 12 patients with CNS-inflammatory syndromes, a range of clinical and radiological presentations were observed, including some suggestive of post-infective ADEM or transverse myelitis and others with more unusual haemorrhagic changes that made classification challenging. A recent MRI study of 37 patients with severe COVID-19 and abnormal brain imaging found three patterns of CNS white matter changes, which could occur in isolation or in combination (Kremer et al., 2020). Pattern 1 featured medial temporal lobe signal abnormalities similar to that seen in viral or autoimmune encephalitis; whereas patterns 2 and 3 featured microhaemorrhages, either in the context of multifocal white matter hyperintense lesions or as separate features, respectively. Whether these patterns represent the same pathology over different timelines, different immunological or other mechanisms, or combinations, is currently unclear, but could have important implications for management decisions, such as the use of steroids, and rehabilitation. In the Kremer et al. (2020) study, haemorrhagic lesions correlated with clinical indicators of disease severity. Especially in the intensive care cohort, it can be unclear when brain injury occurs, as imaging is usually only undertaken when a patient is slow to wake after a prolonged period of ventilation.
Histopathological correlates are now emerging for some lesions. Reichard et al. (2020) described a case similar to those described in the Kremer et al. study and reported features of both vascular and ADEM-like pathology, with macrophages and axonal injury. Conversely, von Weyhern et al. (2020) found lymphocytic panencephalitis and meningitis, and brainstem perivascular and interstitial inflammatory change with neuronal loss as prominent features in six post-mortem patients. In our one case who underwent cranial decompression, brain histology was in keeping with ADEM. Similar to the ADEM-like cases, the GBS cases also largely point to a post-infectious autoimmune mechanism, with most developing the neurological disease within 3 weeks of the documented infection. The risk factors for neurological disease remain unknown, and require further epidemiological study.
The potential mechanisms underpinning the syndromes described include either individually, or in combination, direct viral injury, a secondary hyperinflammation syndrome related to cytokines including IL-6 (Mehta et al., 2020), vasculopathy and/or coagulopathy, post-
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
16
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 18 of 63
infectious inflammation including autoantibody production to neuronal antigens, and the effects of a severe systemic disorder with the neurological consequences of sepsis and hypoxia. Evidence of direct viral infection has proved elusive so far with only a few cases with SARS-CoV-2 in CSF reported, and few supportive histopathological features, though clearly further study would be helpful (Reichard et al., 2020, Von Weyhern et al., 2020). Elevation of pro-inflammatory cytokines was found to correlate with COVID-19 disease severity (Herold et al., 2020; Huang et al., 2020), and some patients responded to IL-1 or IL- 6 blockade (Cavalli et al., 2020; Price et al., 2020); in support of this possible mechanism, transient splenial lesions have been reported in a number of cases, including in children with multisystem inflammatory syndrome (MIS-C), in which elevated cytokines are thought to play a role (Starkey et al., 2017; Abdel-Mannan et al., 2020; Hayashi et al., 2020; Riollano- Cruz et al., 2020). Interestingly, some of the clinical features seen in our youngest patient (Patient 39, aged 16 with pseudotumour cerebri with cranial nerve palsies) overlapped with those seen in MIS-C, including gastrointestinal symptoms, rash and cardiac involvement (Supplementary Table 1). Exact mechanisms in each case will be largely speculative until clear clinical, radiological and histological correlates have been drawn; given the breadth of clinical presentations, it is likely that a number or spectrum of these mechanisms are involved.
Collectively, these cases presented a considerable challenge to diagnose with MRI, neurophysiology including EEG, being difficult to obtain in an intensive care setting in addition to the demands of safe nursing and infection control. In many cases, MRI proved essential for making the diagnosis or confident exclusion of abnormalities, especially in patients in the intensive care unit who were ‘slow to wake’. In addition, controversy remains regarding the optimal treatment options including the use of high dose corticosteroids in viraemic, and often lymphopenic patients, and the potential risks of using IVIG for ADEM and GBS, in patients with pro-thrombotic risk factors such as elevated D-dimer levels.
This is a selective and retrospective study, with the limitations associated with this study design, including bias towards severe disease. Nevertheless, the study has allowed a detailed description of the neurological complications seen during and after COVID-19 infection. Further detailed clinical, laboratory, biomarker and neuropathological studies will help elucidate the underlying pathobiological mechanisms of COVID-19 neurological
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
17
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 19 of 63
Brain
complications. Longitudinal follow-up studies of patients will be necessary to ascertain the long-term consequences of this pandemic.
Acknowledgements
We acknowledge the patients and their families and friends, and the referring clinicians.
Funding
R.W.P is supported by an Alzheimer's Association Clinician Scientist Fellowship and by the UK Dementia Research Institute. R.L.B is supported by a Medical Research Council Clinical Research Training Fellowship. R.W.P, R.N, M.P.L and M.S.Z are supported by the NIHR UCL/UCLH Biomedical Research Centre.
Competing interests
C.C. has sat on an advisory panel for Roche. A.V. and the University of Oxford hold patients and receive royalties for antibody tests. M.S.Z has received lecturing fees for Eisai and UCB pharma. No other authors declare competing interest.
Supplementary material
Supplementary material is available at Brain online.
References
Abdel-Mannan O, Eyre M, Löbel U, Bamford A, Eltze C, Hameed B, Hemingway C, Hacohen Y. Neurologic and radiographic findings associated with COVID-19 infection in children: A case series. JAMA Neurology (in press)
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
18
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 20 of 63
Absoud M, Lim MJ, Appleton R, Jacob A, Kitley J, Leite MI, et al. Paediatric neuromyelitis optica: clinical, MRI of the brain and prognostic features. J Neurol Neurosurg Psychiatry 2015; 86: 470–472.
Beyrouti R, Adams ME, Benjamin L, Cohen H, Farmer SF, Goh YY, et al. Characteristics of ischaemic stroke associated with COVID-19. J Neurol Neurosurg Psychiatry 2020: jnnp- 2020-323586.
Brown E, Gray R, Lo Monaco S, O’Donoghue B, Nelson B, Thompson A, et al. The potential impact of COVID-19 on psychosis: A rapid review of contemporary epidemic and pandemic research. Schizophrenia Research 2020.
Cavalli, G. et al. Interleukin-1 blockade with high-dose anakinra in patients with COVID-19, acute respiratory distress syndrome, and hyperinflammation: a retrospective cohort study. Lancet Rheumatol. 2, e325–e331 (2020).
Dixon L, Varley J, Gontsarova A, Mallon D, Tona F, Muir D, et al. COVID-19-related acute necrotizing encephalopathy with brain stem involvement in a patient with aplastic anemia. Neurology - Neuroimmunology Neuroinflammation 2020; 7 https://nn.neurology.org/content/7/5/e789
Granerod J, Ambrose HE, Davies NW, Clewley JP, Walsh AL, Morgan D, et al. Causes of encephalitis and differences in their clinical presentations in England: a multicentre, population-based prospective study. Lancet Infect Dis 2010; 10: 835–844.
Guan W, Ni Z, Hu Y, Liang W, Ou C, He J, et al. Clinical Characteristics of Coronavirus Disease 2019 in China. New England Journal of Medicine 2020; 382: 1708–1720.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
19
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 21 of 63
Brain
Hayashi, M., Sahashi, Y., Baba, Y., Okura, H. & Shimohata, T. COVID-19-associated mild encephalitis/encephalopathy with a reversible splenial lesion. J. Neurol. Sci. 415, 116941 (2020).
Helms J, Kremer S, Merdji H, Clere-Jehl R, Schenck M, Kummerlen C, et al. Neurologic Features in Severe SARS-CoV-2 Infection. New England Journal of Medicine 2020; 0: null.
Herold, T. et al. Elevated levels of IL-6 and CRP predict the need for mechanical ventilation in COVID-19. J. Allergy Clin. Immunol. 2020, (2020).
Kim JE, Heo JH, Kim HO, Song SH, Park SS, Park TH, et al. Neurological Complications during Treatment of Middle East Respiratory Syndrome. J Clin Neurol 2017; 13: 227–233.
Huang, C. et al. Clinical features of patients infected with 2019 novel coronavirus in Wuhan, China. Lancet 395, 497–506 (2020).
Kirby T. Evidence mounts on the disproportionate effect of COVID-19 on ethnic minorities. The Lancet Respiratory Medicine 2020; 0:
Kremer, S. et al. Brain MRI Findings in Severe COVID-19: A Retrospective Observational Study. Radiology 78, 202222 (2020).
Mao L, Jin H, Wang M, Hu Y, Chen S, He Q, et al. Neurologic Manifestations of Hospitalized Patients With Coronavirus Disease 2019 in Wuhan, China. JAMA Neurol 2020. https://www.ncbi.nlm.nih.gov/pmc/articles/PMC7149362/
Mehta P, McAuley DF, Brown M, Sanchez E, Tattersall RS, Manson JJ. COVID-19: consider cytokine storm syndromes and immunosuppression. The Lancet 2020; 395: 1033– 1034.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
20
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 22 of 63
Pohl D, Alper G, Van Haren K, Kornberg AJ, Lucchinetti CF, Tenembaum S, et al. Acute disseminated encephalomyelitis: Updates on an inflammatory CNS syndrome. Neurology 2016; 87: S38-45.
Price, C. C. et al. Tocilizumab treatment for Cytokine Release Syndrome in hospitalized COVID-19 patients: survival and clinical outcomes. Chest (2020). doi:10.1016/j.chest.2020.06.006
Rábano-Suárez P, Bermejo-Guerrero L, Méndez-Guerrero A, Parra-Serrano J, Toledo- Alfocea D, Sánchez-Tejerina D, et al. Generalized myoclonus in COVID-19. Neurology 2020: 10.1212/WNL.0000000000009829.
Reichard, R. R. et al. Neuropathology of COVID-19: a spectrum of vascular and acute disseminated encephalomyelitis (ADEM)-like pathology. Acta Neuropathol. 140, 1–6 (2020).
Riollano‐Cruz, M. et al. Multisystem Inflammatory Syndrome in Children (MIS‐C) Related to COVID‐19: A New York City Experience. J. Med. Virol. jmv.26224 (2020). doi:10.1002/jmv.26224
Rogers JP, Chesney E, Oliver D, Pollak TA, McGuire P, Fusar-Poli P, et al. Psychiatric and neuropsychiatric presentations associated with severe coronavirus infections: a systematic review and meta-analysis with comparison to the COVID-19 pandemic. The Lancet Psychiatry 2020; 0:
Starkey, J., Kobayashi, N., Numaguchi, Y. & Moritani, T. Cytotoxic Lesions of the Corpus Callosum That Show Restricted Diffusion: Mechanisms, Causes, and Manifestations. RadioGraphics 37, 562–576 (2017).
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
21
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 23 of 63
Brain
Tang N, Li D, Wang X, Sun Z. Abnormal coagulation parameters are associated with poor prognosis in patients with novel coronavirus pneumonia. Journal of Thrombosis and Haemostasis 2020; 18: 844–847.
Toscano G, Palmerini F, Ravaglia S, Ruiz L, Invernizzi P, Cuzzoni MG, et al. Guillain–Barré Syndrome Associated with SARS-CoV-2. New England Journal of Medicine 2020; 0: null.
Tsai L-K, Hsieh S-T, Chang Y-C. Neurological Manifestations in Severe Acute Respiratory Syndrome. 2005; 14: 7.
Umapathi T, Kor AC, Venketasubramanian N, Lim CCT, Pang BC, Yeo TT, et al. Large artery ischaemic stroke in severe acute respiratory syndrome (SARS). J Neurol 2004; 251: 1227–1231.
Varatharaj A, Thomas N, Ellul MA, Davies NWS, Pollak TA, Tenorio EL, et al. Neurological and neuropsychiatric complications of COVID-19 in 153 patients: a UK-wide surveillance study [Internet]. The Lancet Psychiatry 2020; 0
Varga Z, Flammer AJ, Steiger P, Haberecker M, Andermatt R, Zinkernagel AS, et al. Endothelial cell infection and endotheliitis in COVID-19. The Lancet 2020; 395: 1417–1418.
von Weyhern, C. H., Kaufmann, I., Neff, F. & Kremer, M. Early evidence of pronounced brain involvement in fatal COVID-19 outcomes. Lancet 395, e109 (2020)
Willison HJ, Jacobs BC, van Doorn PA. Guillain-Barré syndrome. Lancet 2016; 388: 717– 27.
Zanin L, Saraceno G, Panciani PP, Renisi G, Signorini L, Migliorati K, et al. SARS-CoV-2 can induce brain and spine demyelinating lesions. Acta Neurochir (Wien) 2020: 1–4.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
22
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Zubair AS, McAlpine LS, Gardin T, Farhadian S, Kuruvilla DE, Spudich S. Neuropathogenesis and Neurologic Manifestations of the Coronaviruses in the Age of Coronavirus Disease 2019: A Review [Internet]. JAMA Neurol 2020.
Brain
Page 24 of 63
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
23
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 25 of 63
Brain
Figure legends
Figure 1 Imaging from Patients 12, 13 and 15 (COVID-19 autoimmune and haemorrhagic encephalitis). Axial MRI from three individuals with para-/post-infectious central syndromes. (A–D) Patient 12: axial fluid-attenuated inversion recovery (FLAIR) images show bilateral hyperintensity in the mesial temporal lobes (A and B), hypothalamus (C) temporal lobes and thalamus (D). (E–H) Patient 13: axial T2-weighted (E), diffusion weighted imaging (DWI) (F), susceptibility weighted imaging (SWI) (G) and post-contrast T1-weighted (H) images show multifocal clusters of lesions involving the deep white matter of both cerebral hemispheres, intralesional cyst-like areas of varied sizes, and some peripheral rims of restricted diffusion (F), some haemorrhagic changes (G), and T1 hypointense ‘black holes’ without contrast enhancement (H). (I–P) Patient 15: axial images at the level of the insula and basal ganglia (I–L) and at the level of the temporal lobes and upper pons (M–P). T2-weighted images (I and M), SWI images (J and N), DWI images (K and O) and contrast-enhanced images (L and P). There are extensive confluent areas of T2 hyperintensity (I and M), with haemorrhagic change on SWI imaging (J and N), restricted diffusion on DWI images (K and O) and peripheral contrast-enhancement (arrows in L and P) in the insular region, basal ganglia and left occipital lobe (I–L) as well as in the medial temporal lobes and upper pons (M–P).
Figure 2 Axial MRI (A–D) and histopathology (E–G) from Patient 17, diagnosed with ADEM, and imaging (H–O) from Patient 16, with combined CNS and PNS disease. (A– G) Patient 17: axial T2-weighted (A), SWI (B), post-gadolinium (C and D) images show extensive confluent ‘tumefactive’ lesions involving the white matter of the right cerebral hemisphere, corpus callosum and corona radiata with mass effect, subfalcine herniation (A), clusters of prominent medullary veins (B, short arrows) and peripheral rim enhancement (D, arrows). (E) The white matter shows scattered small vessels with surrounding infiltrates of neutrophils and occasional foamy macrophages extending into the parenchyma (arrow). The endothelium is focally vacuolated but there is no evidence of vasculitis or fibrinoid vessel wall necrosis in any region. There were a few perivascular T cells in the white matter but the cortex appears normal (not shown). (F) CD68 stain confirms foci of foamy macrophages in the white matter, mainly surrounding small vessels. There was no significant microgliosis in the cortex (not shown). (G) Myelin basic protein stain (SMI94) shows areas with focal
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
24
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain
Page 26 of 63
myelin debris in macrophages around vessels in the white matter (arrows) in keeping with early myelin breakdown. There is no evidence of axonal damage on neurofilament stain (not shown). Scale bars: E = 45μm; F and G = 70 μm. (H–O) Patient 16: axial post-gadolinium fat-suppressed T1-weighted images (H) demonstrating pathologically enhancing extradural lumbosacral nerve roots (arrows). Note physiological enhancement of nerve root ganglia (short arrows). Coronal short tau inversion recovery (STIR) image (L) shows hyperintense signal abnormality of the upper trunk of the right brachial plexus (arrow). Initial axial T2 (I and J) and T2-weighted images (K) show multifocal confluent T2 hyperintense lesions involving internal and external capsules, splenium of corpus callosum (I), and the juxtacortical and deep white matter (J), associated with microhaemorrhages (K, arrows). Follow-up T2-weighted images (M and N) show marked progression of the confluent T2 hyperintense lesions, which involve a large proportion of the juxtacortical and deep white matter, corpus callosum and internal and external capsules. The follow-up SWI image (O) demonstrates not only the previously seen microhaemorrhages (arrows) but also prominent medullary veins (short arrows).
Figure 3 Imaging from Patient 27, with cerebral infarction and pulmonary thromboembolism (A–D), and Patient 41, with microhaemorrhages (E–H). (A–D) Patient 27: CT pulmonary angiogram (A) demonstrated large emboli in the right and left pulmonary arteries (arrows). DWI (B), T2-weighted FSE (C) and SWI (D) images show restricted diffusion (B) and T2 hyperintensity (C) in the left basal ganglia and cortical territory of left middle cerebral artery. The SWI image (D) shows haemorrhagic transformation in the basal ganglia (short arrow) and a long intravascular thrombus in a Sylvain branch of the left middle cerebral artery (long arrow). (E–H) Patient 41: chest CT (E) shows severe COVID-19 pneumonitis. SWI images (F–H) demonstrate numerous cerebral microbleeds in the temporal, frontal and parietal lobes, predominantly located at the grey/white matter junction.
Figure 4 Patients 19 and 20 (ADEM including spinal cord). Patient 19: axial T2 (A and C) and DWI (B and D) images show multifocal lesions involving corpus callosum and corona radiata. Axial T2-weighted images of brain MRI and sagittal T2-weighted of the spinal cord acquired on admission (E–H) and after 26 days (I–L). Axial T2-weighted images show multifocal hyperintense lesions in the brainstem (E and I), basal ganglia and supratentorial
25
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 27 of 63
Brain
26
white matter (F and J). The pontomedullary hyperintensities have become more confluent (I) since admission (E). After 26 days, the signal abnormalities in the basal ganglia and the supratentorial white matter (J) are grossly similar to the baseline MRI scan (F). Sagittal and axial T2-weighted images show diffuse high T2-weighted signal intrinsic to the spinal cord at baseline (G and H). After 26 days, the cord oedema has reduced, and the spinal cord lesions appear less confluent and more discrete (K and L).
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Table 1 Summary of clinical features of 43 patients with neurological complications of COVID-19
Brain Page 28 of 63
Cases
Age, median [range]; %male
Days of COVID-19 infection before neurological presentation, median [range]
Main clinical features
Results of note
% Naso- pharyhgeal SARS-CoV-2 PCR+
CSF or brain SARS-CoV-2 PCR+ (x/number tested)
Treatment
Clinical outcome
Encephalopathy (delirium/psychosis) (n = 10)a
57.5 [39–72]; 40
4.5 [−4 to +21]
Delirium; psychosis
Acellular CSF (6/6); non-specific MRI changes (3/10)
80 (8/10)
(0/0)
Supportive (9/10); steroids 1/10
Complete recovery (7/10); partial (2/10)
Inflammatory CNS syndromes (para- /post- infectious) (n = 12)a
53 [27–66]; 33
9 [−6 to +27]
Reduced consciousness (7/12); UMN signs (10/12)
Abnormal CSF (6/11) Abnormal MRI (11/12)
67 (8/12)
(0/7)
Corticosteroids (10/12); IVIG (3/12)
Recovery: complete (1/12); partial (10/12); none (death 1/12)
Stroke (n = 8)a
62.5 [27–85]; 75
8[−2 to +22]
Large vessel ischaemic stroke
4/8 PE
6/6 High D–dimer
75 (6/8)
NA
Low molecular weight heparin (7/8); apixaban (1/8)
Incomplete recovery (7/8); death (1/8)
Peripheral syndromes (n = 8)
GBS (n = 7)
57 [20–63]; 100
13 [−1–21]
Cranial and peripheral neuropathy
43 (3/7)
NT
IVIG (7/7)
Incomplete recovery (5/7 GBSDS 2)
Plexopathy (n = 1)
60; 100
14
Painless weakness
100 (1/1)
NT
IV steroids (1/1)
Incomplete recovery (1/1)
Miscellaneous and uncharacterized (n = 5)
20 [16–40]; 40
10 [6–26]
Raised ICP; seizures; myelitis
Abnormal CSF (2/4) Abnormal MRI brain (4/5)
60 (3/5)
(0/1)
Varied (AED; steroids (1/5); tLP)
Recovery complete (1/5); partial (3/5); nil (1/5)
AED = antiepileptic drug; GBSDS = Guillain Barré disability score; ICP = intracranial pressure; tLP = therapeutic lumbar puncture; NT = not tested; PE = pulmonary thromboembolism; UMN = upper motor neuron.
aFeatures of eight individual patients for encephalopathy (delirium/psychosis), inflammatory CNS syndromes (para/post-infectious) and stroke described in Tables 2–4. All patient details are available in the Supplementary material.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 29 of 63 Brain
Table 2 Eight patients with spontaneously improving encephalopathies (Patients 1–8)
Patient
1
2
3
4
5
6
7
8
Age, M/F, ethnicity, COVID-19 diagnosis/severity
65, F, White, definite/mild
72, M, White, definite/critical
59, F, Black, definite/mild
58, M, Black, definite/mild
52, F, White, probable/mild
39, F, Asian, definite/critical
55, F, White, definite/severe
68, M, Black, definite/mild
Final neurological diagnosis
Hypoactive delirium
Hypoactive delirium
Delirium
Delirium
Delirium
Delirium
Delirium and psychosis
Hyperactive delirium
Initial neurological symptoms
Fluctuating confusion; reversal of sleep-wake cycle
Confusion; malaise; loss of appetite
Fluctuating confusion
Confusion; nonsensical speech; repetitive behaviour; disorientation; delusional thoughts; headache
Fluctuating consciousness; delirium
Delirium; hallucinations about experiences in countries not previously visited; reversed sleep/wake cycle
Confusion; agitation; persecutory delusions; visual hallucinations; combative behaviour; headaches
Cognitive impairment; gait disturbance; two falls
Key neurological signs
Disorientated to time and place; impaired insight; bradyphrenia; polyminimyoclonus; old left homonymous hemianopia
Cognitive impairment; increased limb tone; brisk reflexes
Fluctuating attention and cognition; bradyphrenia; dyspraxia.
Bilateral intention tremor; heel-shin ataxia
Cognitive impairment; reduced verbal fluency
Cognitive impairment
No focal signs
Disorientation; intermittent agitation; unable to follow commands; speaking a few words only; bilateral extensor plantars
D-dimer (μg/l; 0– 550)
1190
1730
NR
970
NR
2430
1200
NR
Neurological treatments; recovery
Supportive; complete
Supportive; complete/rehab
Supportive; complete
Supportive; complete
Supportive; complete
Melatonin; on- going cognitive impairment
Haloperidol, risperidone; improving
1g IVMP 3 days; ongoing improvement
Imaging, further investigations and Patients 9 and 10 are provided in the Supplementary material. F = female; IVMP = intravenous methylprednisolone; M = male; NR = no result.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Table 3 Eight patients with neuroinflammatory diseases (Patients 11–18)
Brain Page 30 of 63
Patient
11
12
13
14
15
16
17
18
Age, M/F, ethnicity,
COVID-19 diagnosis/ severity
65, F, Black, definite/severe
66, F, White, definite/mild
52, M, Asian, definite/critical
60, M, Asian, definite/critical
59, F, Asian, definite/mild
52, M, White, definite/critical
47, F, other, probable/severe
54, F, mixed, probable/mild
Final neurological diagnosis
Possible post- infectious encephalitis (presumed autoimmune)
Encephalitis
ADEM (with haemorrhage)
ADEM (with haemorrhage)
ADEM (with necrosis and haemorrhage)
ADEM (with haemorrhage) and acute demyelinating polyradiculoneuropathy
ADEM (with haemorrhage)
ADEM
Imaging: neuraxis (summary)
MRI brain normal
MRI brain: T2 hyperintense signal changes in upper pons, limbic lobes, medial thalami and subcortical cerebral white matter
MRI brain: multiple clusters of lesions in the deep cerebral white matter. Cyst-like areas of varied sizes, some with haemorrhagic foci and peripheral rims of restricted diffusion
MRI brain: multifocal and confluent areas of signal change in the cerebral hemispheric white matter with extensive microhaemorrhages in the subcortical regions
MRI brain (Day 6): extensive, confluent and largely symmetrical areas throughout brainstem, limbic and insular lobes, superficial subcortical white matter and deep grey matter. Clusters of microhaemorrhages, restricted diffusion and peripheral rim enhancement
MRI brain: multifocal confluent lesions in internal and external capsules, splenium and deep white matter of cerebral hemispheres. Over 5 days, lesions increased in size and showed multiple microhaemorrhages and extensive prominent medullary veins. Components of brachial and lumbosacral plexus showed increased signal and enhancement
Severe right hemispheric vasogenic oedema with a leading edge on contrast imaging. Smaller areas of T2 hyperintense changes in the left hemisphere. Marked mass- effect with 10 mm leftwards midline shift, and mild subfalcine herniation
Multiple large lesions with peripheral rim restriction in periventricular white matter of both cerebral hemispheres
D-dimer if raised; CSF studies; all neuronal antibodies performed were negative
1800 μg/l (0– 550); CSF matched OCB, viral PCR negative
1599 ng/ml (0– 230); CSF protein raised, OCB, viral PCR including SARS- CoV-2 negative
80 000 μg/l (0– 550); OCB negative, viral PCR and antibodies negative
3330 mg/l (250– 750); CSF OCB negative, viral PCR negative including SARS-CoV-2
2033 mg/l (250–750); CSF OP raised, viral PCR negative including SARS-CoV-2
NR; CSF protein raised, viral PCR negative
1160 μg/l (0–550); CSF NR
NR 19 (90% lymph); 0.33; OCB negative, CSF culture scanty Staphylococcus capitis (likely contamination)
Treatments for neurological diagnosis; recovery
1g IVMP 3 days, oral prednisolone taper, levetiracetam,
1g IVMP 3 days then oral prednisolone taper, IVIG; incomplete
Supportive; incomplete but ongoing
1g IVMP 3 days; incomplete ongoing
Intubation, ventilation; levetiracetam, aciclovir and ceftriaxone, dexamethasone; no response, died
Intubation and ventilation, 1g IVMP 5 days, IVIG; incomplete ongoing recovery
Intubation, hemicraniectomy, 1g IVMP 5 days, oral prednisolone,
1g IVMP 3 days, then oral prednisolone; incomplete ongoing recovery
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 31 of 63 Brain
clonazepam; incomplete
IVIG; incomplete ongoing recovery
Diagnosis, imaging and further investigations for Patients 19–22 are provided in the Supplementary material. F = female; IVMP = intravenous methylprednisolone; M = male; NR = no result; OCB = oligoclonal band; OP = .
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Table 4 Eight patients with stroke (Patient 23–30)
Brain Page 32 of 63
Patient
23
24
25
26
27
28
29
30
Age, M/F, ethnicity, COVID- 19 diagnosis, severity, time from COVID onset
61, M, White, definite/mild, 2 days
64, M, White, definite/severe,15 days
64, M, White definite/severe, NK
53, F, Asian, definite/severe, 22 days
58, M, Black, probable/mild, 2 days
85, M, White, definite/mild, 10 days
73, M, Asian, definite/mild, 8 days
27, F, White, probable/mild, 0 days
Stroke type, observed/implicated mechanism; venous thromboembolism
Ischaemic right middle cerebral artery occlusion; yes, PE
Ischaemic, vertebral- basilar artery occlusion; yes, PE
Ischaemic bilateral ACA-MCA and MCA- PCA cortical and deep borderzone infarct; no
Ischaemic, vertebral-basilar artery occlusion; no
Ischaemic, proximal left middle cerebral artery occlusion; yes PE
Ischaemic, left posterior cerebral artery occlusion; no
Ischaemic basilar artery occlusion, no
Ischaemic left internal cerebral artery occlusion; yes PE
Fibrinogen (g/l; 1.5–4.0), D- dimer (μg/l; 0–550), Prothrombin time (s; 10–12)
4.63, 27190, 10.7
9.5, 80000, 11.6
8.82, 29000, 12.6
2.91, 7750, 34.4
3.15, 75320, 12,2
5.3, 16100, 11.3
NR, NR, 14.9
NR, NR, 11.5
Brain imaging (summary)
MRI: acute infarct in the right corpus striatum. Multiple supra- and infra- tentorial cortical and subcortical microhaemorrhages
MRI: (1st event): acute left vertebral artery thrombus and acute left posterior-inferior cerebellar artery territory infarction with microhaemorrhages. 2nd event - 7 days later: bilateral acute posterior cerebral artery territory infarcts despite therapeutic anticoagulation
MRI: subacute infarcts within the deep internal border zones of the cerebral hemispheres bilaterally, and within the left frontal white matter. Background moderate small vessel disease and established cortical infarcts, in arterial border zone territories
Non-contrast CT: showed acute right parietal cortical and left cerebellar infarct with mass effect and hydrocephalus, despite therapeutic anticoagulation
MRI: extensive evolving left MCA infarct with evidence of petechial haemorrhage and associated mass-effect as described. Persistent occlusion of the left M2 MCA branches
Non-contrast CT: showed hyperdensity consistent with thrombus in the left posterior cerebral artery and acute infarction in the left temporal stem and cerebral peduncle
MRI: acute infarction in the right thalamus, left pons, right occipital lobe and right cerebellar hemisphere
CT: right middle cerebral artery and right anterior cerebral artery territory infarction
Tissue plasminogen activator, mechanical ventilation, anti- thrombotic therapy
No, no, LMWH
No, no, LMWH
No, no, LMWH
No, no, LMWH
No, no, LMWH
No, no, aspirin 7 days then switched to apixaban
Yes, no, aspirin 5 days then switched to LMWH
Aspirin 10 days then LMWH
Outcome status
Rehabilitation unit
Rehabilitation unit
Remains static in ICU (Day 31)
Died
Rehabilitation unit
Rehabilitation unit
Stroke unit
Rehabilitation unit
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 33 of 63 Brain
ACA = anterior cerebral artery F = female; ICU = intensive care unit; LMWH = low molecular weight heparin; M = male; MCA = medial cerebral artery; NK = not known; NR = no result; PCA = posterior cerebral artery; PE = pulmonary embolism.
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain Page 34 of 63
figure 1
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 35 of 63 Brain
figure 2
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Brain Page 36 of 63
Figure 3
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
Page 37 of 63 Brain
51x45mm (300 x 300 DPI)
ScholarOne, 375 Greenbrier Drive, Charlottesville, VA, 22901 Support (434) 964 4100
Downloaded from https://academic.oup.com/brain/advance-article/doi/10.1093/brain/awaa240/5868408 by guest on 11 October 2020
